23The Sewing Computer – Screen Display
Screen Display
Stitch Selection – Stitches – Functions
Stitch Selection
touch the stitch of your choice
•
the stitch is highlighted in blue
• every stitch in the Stitch Altering Area (SAA) is displayed
with its number
Altering the Stitch Width
turn the upper knob
The altered stitch width is shown in
two different ways:
•
stitch width bar 0-9 (0-5.5) is
displayed as yellow area
• altered width is visible on stitch
width bar (highlighted in blue), in
addition the actual setting is
shown (blue number)
•
the basic setting is always visible
when a change has been made,
e.g. 3.5mm (black bar)
•
stitch width can be altered from
0mm to 9mm when using coded
feet
•
stitch width can be altered from 0
to 5.5mm max. when using
non-coded feet, the stitch width
bar automatically shows 0-5.5mm
Altering the Stitch Length
turn the lower knob
The altered stitch length is shown in
two different ways:
• stitch length bar 0-5 is displayed
as yellow area
•
altered length is visible on stitch
length bar (highlighted in blue), in
addition the actual setting is
shown (blue number)
• the basic setting is always visible
when a change has been made,
e.g. 1.5mm (black bar)
• stitch length can be altered from
0mm to 5mm on most stitches
Display of Selected Stitch
• a graphic of the selected stitch is
visible in the left portion of the
screen
• changes to stitches can be seen on
screen
