11
Setting up the sewing computer
Free Hand System (FHS) presser foot lifter
Raising and lowering the presser foot
• knee-operated presser foot lever to raise
and lower the presser foot - your hands
remain free to guide the fabric
• with your knee push lever to the right
• the feed dog is lowered simultaneously
• the feed dog is raised as soon as the
first stitch is sewn
CFL Sewing Light
Contrary to an ordinary bulb, the CFL
sewing light has a better illumination and a
longer life.
Attaching the presser foot lifter
• insert the lever into respective opening
- you should be able to operate the FHS
with your knee in your normal sitting
position
Please note that a defec tive
CFL sewing light must ONLY
be replaced by an authorized
technician. The sewing
computer must be brought to
an authorized BERNINA
dealer!
Slide-on table
To remove
• raise needle and presser foot
• use slight pressure - with your thumb
against the housing and the index against
the table - to slide it off to the left
Seam guide
• slide into extension table guides from left
or right
• can be moved over full table length
Scale
• «0» corresponds to the center needle
position
Larger sewing surface
• the slide-on table increases the sewing
surface
To attach
• raise needle and presser foot
• slide over free-arm to the right until it
engages
Always raise needle and
presser foot when attaching
or removing the slide-on
table!
Your dealer can adjust the
FHS if necessary.
&
