Bernina Aurora 440QE User Manual

16
Setting up the sewing computer
Removing the needle
• raise the needle
• turn power switch to «0» (off)
• lower the presser foot
• loosen the needle clamp screw
• pull the needle down to remove
Changing the needle
!
Refer to the
safety instructions!
To remove the bobbin case
• raise the needle
• turn power switch to «0» (off)
• open the bobbin cover
• grasp the latch of the bobbin case
• remove case
* pictures = aurora 450
Bobbin case*
To insert the bobbin case
• hold the bobbin case latch
• aurora 430 / 440 QE: the finger on the
case should point upwards
• aurora 450: bobbin case opening points
up
• insert so that it clicks into place
Bobbin thread cutter
• take the thread over cutter A and cut it
• close the bobbin cover
• the bobbin thread does not have to be
brought up as the loose end is just the
right length to start sewing
!
Refer to the
safety instructions!
Inserting the needle
• flat side of needle to the back
• insert the needle as far as it will go
• tighten the needle clamp screw
A
032907.52.04_1103_a430_a440_a450_EN

Bernina Aurora 440QE Specifications

General

Maximum Sewing Speed	900 stitches per minute
Stitch Width	5.5 mm
Stitch Length	5 mm
Thread Cutter	Manual
Free Arm	Yes
Memory	Yes
Speed Control	Yes
Start/Stop Button	Yes
Needle Up/Down	Yes
Display	LCD
USB Port	No
Hook System	CB
Type	Electronic
Number of Stitches	379
Alphabets	4
Lighting	LED
Buttonholes	3
Presser Feet	Included
