48
3. INSTALLATION INSTRUCTIONS
• Attach the decorative upper freezer drawer cover
(#5) using the tabs to secure it to the drawer.
• Attach the decorative side trim seals (#2) and
(#3) (optional). Note: side trim pieces may require
some trimming if gap is too small to allow them
to be pushed in; some force may be required.
Remove the protective film from the double-
sided tape to secure the trim to the front face of
the fridge cabinet.
3.6 Hinge Adjustment and Reversing
the Door Swing
ADJUSTING THE SPRING TENSION OF THE HINGES
• Use a drill to adjust the tension of the upper and
lower hinges of the fridge door. Set the hinge
adjustment screw to position "I" from position
"O".
WARNING:
The door must be fully open during this
adjustment.
WARNING:
The hinge tension adjustment must be
Double-sided tape
To Next Page
