Adjusting the PUSH arm
system
1. Telescopic part
2. Drive arm
1. Open the door and connect the
door fitting with the drive arm (do
not tighten the lock screws).
2. Close the door and keep it closed.
3. Turn the drive arm until the
telescopic part is at an angle of 90°
to the door.
4. Tighten the telescopic part with the
lock screws.
