Best 45H - Escutcheon Assemblies

Trim Parts
40H Series Service Manual
5–23
ESCUTCHEON ASSEMBLIES
J trim outside
escutcheons
J trim outside escutcheon assemblies are described in the table and
figures below.
Item Description Functions Part number
1 C44091
2
C44092
3
C44093
4
a. The keyed visual indicator may also be used with IND, INL, and TD function locks.
D44094
5
LEL, L
EU N, NX, NXEL, NXEU
A, AB, AT, B, BA, BW, B5, B7, C,
CHB, D, DEL, DEU, G, HJ, IND,
INL, R, RHB, S, T, TA, TD, TDEL,
TDEU, TWEL, TWEU, W, WEL,
WEU
L, LB, LT
H, HJ
a
L, LB, LT
D44095
Figure 5.27 Outside J trim escutcheons
1 2345
Outside escutcheon
Outside escutcheon
Outside esc utcheon
Outside esc utcheon for key ed
visual indicator
Outside esc utcheon for
privacy visual indicator (with
emergency key)
