Mortise Case Parts
40H Series Service Manual
4–5
AT, C, D, INL, R, W,
ZD, XR function
case parts list
Refer to Figure 4.2 and the table below to find the part you need.
Item
Part No.
a
a. For a complete case assembly, use C45507 and reconfigure the shuttle screws as
needed. See
Changing the function for universal cases
on page 6-5. To order a
“case only” lock, which includes a mortise case, faceplate, and strike, see page 4–62.
Qty. Description
1 A34087
2 D44010
3 C45030
4 B45040
5 B45020
6 C44106
7 A34120
8 C44110
9 C44144
10 B45090
11 B44166
12 C44142
13 A44188
14 B44190
15 C44100
16 B44194
17 C44148
18 A44184
19 C44146
20 A44193
21 C45010
22 C45000
4
Case cover mounting screw
1 Cover
1 Locking lever and toggle assembly
1 Key release shuttle assembly
1 Latchbolt sub-assembly
1 Turn knob hub (non-deadbolt)
1 Turn knob hub spacer
1 Key release lever
1 Cylinder retainer
1 Cylinder retainer assembly
1 Fusible link molded assembly
1 Auxiliary bolt
1 Toggle roller
1 Toggle lever spring
1 Toggle lever
1 Deadlocking lever spring
1 Deadlocking lever
1 Deadlocking lever pin
2
Hub
1 Release lever spring
1 Release lever sub-assembly
1 Case sub-assembly
