Mortise Case Parts
40H Series Service Manual
4–7
LT function case
parts list
Refer to Figure 4.3 and the table below to find the part you need.
Item
Part No.
a
a. For a complete case, use C45520. To order a “case only” lock, which includes a
mortise case, faceplate, and strike, see page 4–62.
Qty. Description
1 A34087
2 D44010
3 C45030
4 B45040
5 B45020
6 C44104
7 A34032
8 C44110
9 B44166
10 A44188
11 B44190
12 C44100
13 C44146
14 A44193
15 C45010
16 C45000
4
Case cover mounting screw
1 Cover
1 Locking lever and toggle assembly
1 Key release shuttle assembly
1 Latchbolt sub-assembly
1 Turn knob hub (deadbolt)
1 Turn knob hub cam
1 Key release lever
1 Fusible link molded assembly
1 Toggle roller
1 Toggle lever spring
1 Toggle lever
2
Hub
1 Release lever spring
1 Release lever sub-assembly
1 Case sub-assembly
