Mortise Case Parts
40H Series Service Manual
4–11
NX function case
parts list
Refer to Figure 4.5 and the table below to find the part you need.
Item
Part No.
a
a. For a complete case, use C45506. To order a “case only” lock, which includes a
mortise case, faceplate, and strike, see page 4–62.
Qty. Description
1 A34087
2 D44010
3 C45030
4 B45040
5 B45020
6 C44106
7 A34120
8 C44110
9 B44166
10 C44142
11 A44188
12 B44190
13 C44100
14 B44194
15 C44148
16 A44184
17 C44146
18 A44193
19 C45010
20 C45000
4
Case cover mounting screw
1 Cover
1 Locking lever and toggle assembly
1 Key release shuttle assembly
1 Latchbolt sub-assembly
1 Turn knob hub (non-deadbolt)
1 Turn knob hub spacer
1 Key release lever
1 Fusible link molded assembly
1 Auxiliary bolt
1 Toggle roller
1 Toggle lever spring
1 Toggle lever
1 Deadlocking lever spring
1 Deadlocking lever
1 Deadlocking lever pin
2
Hub
1 Release lever spring
1 Release lever sub-assembly
1 Case sub-assembly
