Mortise Case Parts
40H Series Service Manual
4–17
B function case
parts list
Refer to Figure 4.8 and the table below to find the part you need.
Item
Part No.
a
a. For a complete case, use C45510. To order a “case only” lock, which includes a
mortise case, faceplate, and strike, see page 4–62.
1 A34087
2 D44010
3 C45030
4 B45060
5 B45020
6 C44104
7 A34120
8 C44110
9 C44144
10 B45090
11 B44166
12 A44188
13 B44190
14 C44100
15 C44146
16 A44193
17 C45010
18 C45000
Qty. Description
4 Case cover mounting screw
1 Cover
1 Locking lever and toggle assembly
1 Deadbolt sub-assembly
1 Latchbolt sub-assembly
1 Turn knob hub (deadbolt)
1 Turn knob hub spacer
1 Key release lever
1 Cylinder retainer
1 Cylinder retainer assembly
1 Fusible link molded assembly
1 Toggle roller
1 Toggle lever spring
1 Toggle lever
2
Hub
1 Release lever spring
1 Release lever sub-assembly
1 Case sub-assembly
To Next Page
