Mortise Case Parts
40H Series Service Manual
4–23
G, B5, B7, function
case parts list
Refer to Figure 4.11 and the table below to find the part you need.
Item
Part No.
a
a. For a complete case, use C45508. To order a “case only” lock, which includes a
mortise case, faceplate, and strike, see page 4–62.
1 A34087
2 D44010
3 C45030
4 B45060
5 B45020
6 C44104
7 A34120
8 C44110
9 C44144
10 B45090
11 B44166
12 A44188
13 B44190
14 C44100
15 C44146
16 A44193
17 C45010
18 C45000
Qty. Description
4 Case cover mounting screw
1 Cover
1 Locking lever and toggle assembly
1 Deadbolt sub-assembly
1 Latchbolt sub-assembly
1 Turn knob hub (deadbolt)
1 Turn knob hub spacer
1 Key release lever
1 Cylinder retainer
1 Cylinder retainer assembly
1 Fusible link molded assembly
1 Toggle roller
1 Toggle lever spring
1 Toggle lever
2 Hub
1 Release lever spring
1 Release lever sub-assembly
1 Case sub-assembly
