Mortise Case Parts
40H Series Service Manual
4–29
L function case
parts list
Refer to Figure 4.14 and the table below to find the part you need.
Item
Part No.
a
a. For a complete case, use C45509. To order a “case only” lock, which includes a
mortise case, faceplate, and strike, see page 4–62.
1 A34087
2 D44010
3 C45030
4 B45060
5 B45020
6 C44104
7 B34032
8 C44110
9 B44166
10 A44188
11 B44190
12 C44100
13 C44146
14 A44193
15 C45010
16 C45000
Qty. Description
4 Case cover mounting screw
Cover
Locking lever and toggle assembly
Deadbolt sub-assembly
Latchbolt sub-assembly
Turn knob hub (deadbolt)
Turn knob hub cam
Key release lever
Fusible link molded assembly
Toggle roller
Toggle lever spring
Toggle lever
1
1
1
1
1
1
1
1
1
1
1
2 Hub
1 Release lever spring
1 Release lever sub-assembly
1 Case sub-assembly
