Mortise Case Parts
40H Series Service Manual
4–33
TA function case
parts list
Refer to Figure 4.16 and the table below to find the part you need.
Item
Part No.
a
a. For a complete case, use C45515. To order a “case only” lock, which includes a
mortise case, faceplate, and strike, see page 4–62.
1 A34087
2 D44010
3 C45032
4 B45060
5 B45020
6 C44104
7 B34032
8 C44110
9 C44144
10 B45090
11 B44166
12 A44188
13 B44190
14 C44100
15 C44146
16 A44193
17 C45010
18 C45000
Qty. Description
4 Case cover mounting screw
Cover
“F” Locking lever sub-assembly
Deadbolt sub-assembly
Latchbolt sub-assembly
Turn knob hub (deadbolt)
Turn knob hub cam
Key release lever
Cylinder retainer
Cylinder retainer assembly
Fusible link molded assembly
Toggle roller
Toggle lever spring
Toggle lever
1
1
1
1
1
1
1
1
1
1
1
1
1
2 Hub
Release lever spring1
1 Release lever sub-assembly
Case sub-assembly1
