Mortise Case Parts
40H Series Service Manual
4–35
AD, WD, YD function
case parts list
Refer to Figure 4.17 and the table below to find the part you need.
Item
Part No.
a
a. For a complete case, use C45512. To order a “case only” lock, which includes a
mortise case, faceplate, and strike, see page 4–62.
1 A34087
2 D44010
3 B45060
4 C44104
5 A34194
6 C44111
7 C44144
8 B45090
9 C45000
Qty. Description
4 Case cover mounting screw
Cover
Deadbolt sub-assembly
Turn knob hub (deadbolt)
Spacer for 38/39H
Modified key release lever
Cylinder retainer
Cylinder retainer assembly
Case sub-assembly
1
1
1
1
1
1
1
1
