Mortise Case Parts
40H Series Service Manual
4–37
RD function case
parts list
Refer to Figure 4.18 and the table below to find the part you need.
a. For a complete RD (RH) function case, use C45513.
For a complete RD (LH) function case, use C45514.
To order a “case only” lock, which includes a mortise case, faceplate, and strike, see
page 4–62.
b. For information to order screws, see page 5–18.
Item
Part No.
a
Qty.
Description
1 A34087 4 Case cover mounting screw
b
2 D44010
1 Cover
3 B45060
1 Deadbolt sub-assembly
4 C44107 1 Turn knob hub (deadbolt – machined for RD (RH))
not shown
C44109
1 Turn knob hub (deadbolt – machined for RD (LH))
5 A34194
1 Spacer for 38/39H
6
C44144
1 Cylinder retainer
7
B45090
1 Cylinder retainer assembly
8
C44111
1 Modified key release lever
9
C45000
1 Case sub-assembly
