Mortise Case Parts
40H Series Service Manual
4–41
DEU function case
parts list
Refer to Figure 4.20 and the table below to find the part you need.
a. For a complete case, determine what type of solenoid and optional sensors you need.
Then use the table below to find the part number for the case. To order a “case only”
lock, which includes a mortise case, faceplate, and strike, see page 4–63.
b. To obtain the parts for the electronic locking toggle assembly, order:
❥ locking slide (B44611)
❥ locking bar (A44612)
❥ electronic locking toggle (B44627)
❥ toggle screws (see
Screw kits
on page 5–19)
.
Sensors Case part number
Door Latch RQE 12 V solenoid 24 V solenoid
■
C45708 C45709
■
C45552 C45557
■
C45558
■■
C45560
■
C45556
■■■
C45553
C45555
■
C45551
C45554
C45559
Item
Part No.
a
Qty. Description
1 A34087
4
Case cover mounting screw
2 D44010
1 Cover
3 A60452
1 Door status switch
4 B44615
1 Latchbolt sensor switch assembly
5 A34236
1 Wire strain relief
6 B44602
2 RQE and latch status switch holder
7 A44601 1 Door position clip
8 B44613
1 12V solenoid
not shown
B44610
1 24V solenoid
9 A44622
1 Strain relief
10 B44616
1 RQE switch assembly (monitors cover side)
11
B44624
1 RQE switch assembly (monitors case side)
12
C44110
1 Key release lever
13
B45020
1 Latchbolt sub-assembly
14
C44144
1 Cylinder retainer
15
B45090
1 Cylinder retainer assembly
16
B44166
1 Fusible link molded assembly
17
C44142
1 Auxiliary bolt
18
C45000
1 Case sub-assembly
19
A44234
1 Self tapping screw
20
B44194
1 Deadlocking lever spring
21
C44148
1 Deadlocking lever
22
A44184
1 Deadlocking lever pin
23
C44539
1 Electrified hub (RH)
24
C44538
1 Electrified hub (LH)
25
b
1 Electronic locking toggle assembly
26
A44193 1 Release lever spring
27
C45010
1 Release lever sub-assembly
To Next Page
