Mortise Case Parts
40H Series Service Manual
4–43
WEL function case
parts list
Refer to Figure 4.21 and the table below to find the part you need.
a. For a complete case, determine what type of solenoid and optional sensors you need.
Then use the table below to find the part number for the case. To order a “case only”
lock, which includes a mortise case, faceplate, and strike, see page 4–63.
b. To obtain the parts for the electronic locking toggle assembly, order:
■ locking slide (B44611)
■ locking bar (A44612)
■ electronic locking toggle (B44627)
■ toggle screws (see Screw kits on page 5–19) .
Sensors Case part number
Door Latch RQE 12 V solenoid 24 V solenoid
■
C45714 C45715
■
C45683 C45688
■
C45689
■■
C45691
■
C45687
■■■
C45684
C45686
■
C45682
C45685
C45690
Item
Part No.
a
Qty. Description
1 A34087
4
Case cover mounting screw
2 D44010 1 Cover
3 A60452 1 Door status switch
4 B44615 1 Latchbolt sensor switch assembly
5 A34236 1 Wire strain relief
6 B44602 2 RQE and latch status switch holder
7 A44601 1 Door position clip
8 B44613 1 12V solenoid
not shown
B44610 1 24V solenoid
9 A44622 1 Strain relief
10 B44616 1 RQE switch assembly (monitors cover side)
11
B44624 1 RQE switch assembly (monitors case side)
12
C44110 1 Key release lever
13
B45020 1 Latchbolt sub-assembly
14
C44144 1 Cylinder retainer
15
B45090 1 Cylinder retainer assembly
16
B44166 1 Fusible link molded assembly
17
C44142 1 Auxiliary bolt
18
C45000 1 Case sub-assembly
19
A44234 1 Self tapping screw
20
B44194 1 Deadlocking lever spring
21
C44148 1 Deadlocking lever
22
A44184 1 Deadlocking lever pin
23
C44538 1 Electrified hub (LH)
24
C44539 1 Electrified hub (RH)
25
b
1 Electronic locking toggle assembly
26
A44193 1 Release lever spring
27
C45010 1 Release lever sub-assembly
