Mortise Case Parts
40H Series Service Manual
4–45
WEU function case
parts list
Refer to Figure 4.22 and the table below to find the part you need.
a. For a complete case, determine what type of solenoid and optional sensors you need.
Then use the table below to find the part number for the case. To order a “case only”
lock, which includes a mortise case, faceplate, and strike, see page 4–63.
b. To obtain the parts for the electronic locking toggle assembly, order:
■ locking slide (B44611)
■ locking bar (A44612)
■ electronic locking toggle (B44627)
■ toggle screws (see Screw kits on page 5–19).
Sensors Case part number
Door Latch RQE 12 V solenoid 24 V solenoid
■
C45712 C45713
■
C45672 C45677
■
C45678
■■
C45680
■
C45676
■■■
C45673
C45675
■
C45671
C45674
C45679
Item
Part No.
a
Qty. Description
1 A34087
4 Case cover mounting screw
Cover
Door status switch
Latchbolt sensor switch assembly
Wire strain relief
2 D44010
1
3 A60452
1
4 B44615
1
5 A34236
1
6 B44602
2
RQE and latch status switch
holder
Door position clip
12V solenoid
24V solenoid
Strain relief
RQE switch assembly (monitors cover side)
RQE switch assembly (monitors case side)
Key release lever
Latchbolt sub-assembly
Cylinder retainer
Cylinder retainer assembly
Fusible link molded assembly
Auxiliary bolt
Case sub-assembly
Self tapping screw
Deadlocking lever spring
Deadlocking lever
Deadlocking lever pin
Electrified hub (LH)
Electrified hub (RH)
Electronic locking toggle assembly
Release lever spring
Release lever sub-assembly
7 A44601
1
8 B44613
1
not shown
B44610
1
9 A44622
1
10 B44616
1
11
B44624
1
12
C44110
1
13
B45020
1
14
C44144
1
15
B45090
1
16
B44166
1
17
C44142
1
18
C45000
1
19
A44234
1
20
B44194
1
21
C44148
1
22
A44184
1
23
C44538
1
24
C44539
1
25
b
1
26
A44193
1
27
C45010
1
