Mortise Case Parts
40H Series Service Manual
4–49
NXEU function case
parts list
Refer to Figure 4.24 and the table below to find the part you need.
a. For a complete case, determine what type of solenoid and optional sensors you need.
Then use the table below to find the part number for the case. To
order a “case only”
lock, which includes a mortise case, faceplate, and strike, see page 4–63.
b. To obtain the parts for the electronic locking toggle assembly, order:
■ locking slide (B44611)
■ locking bar (A44612)
■ electronic locking toggle (B44627)
■ toggle screws (see
Screw kits
on page 5–19)
.
Sensors Case part number
Door Latch RQE 12 V solenoid 24 V solenoid
■
C45704 C45705
■
C45530 C45535
■
C45536
■■
C45538
■
C45534
■■■
C45531
C45533
■
C45529
C45532
C45537
Item
Part No.
a
Qty. Description
1 A34087 4 Case cover mounting screw
Cover
Door status switch
Latchbolt sensor switch assembly
Wire strain relief
2 D44010 1
3 A60452 1
4 B44615 1
5 A34236 1
6 B44602 2 RQE and latch status switch holder
Door position clip
12 V solenoid
24 V solenoid
Strain relief
RQE switch assembly (monitors cover side)
RQE switch assembly (monitors case side)
Latchbolt sub-assembly
Fusible link molded assembly
Auxiliary bolt
Case sub-assembly
Self tapping screw
Deadlocking lever spring
Deadlocking lever
Deadlocking lever pin
Electrified hub (LH)
Electrified hub (RH)
Electronic locking toggle assembly
Release lever spring
Release lever sub-assembly
7 A4601 1
8 B44613 1
not shown
B44610 1
9 A44622 1
10 B44616 1
11
B44624 1
12
B45020 1
13
B44166 1
14
C44142 1
15
C45000 1
16
A44234 1
17
B44194 1
18
C44148 1
19
A44184 1
20
C44538 1
21
C44539 1
22
b
1
23
A44193 1
24
C45010 1
To Next Page
