Mortise Case Parts
40H Series Service Manual
4–53
TDEU function case
parts list
Refer to Figure 4.2 and the table below to find the part you need.
a. For a complete case, determine what type of solenoid and optional sensors you need.
Then use the table below to find the part number for the case. To order a “case only”
lock, which includes a mortise case, faceplate, and strike, see page 4–63.
b. To obtain the parts for the electronic locking toggle assembly, order:
■ locking slide (B44611)
■ locking bar (A44612)
■ electronic locking toggle (B44627)
■ toggle screws (see
Screw kits
on page 5–19)
.
Sensor
RQE
Case part number
12 V solenoid 24 V solenoid
C45586■ C45586
C45724
C45725
Item
Part No.
a
Qty. Description
1 A34087
4 Case cover mounting screw
2 D44010
1 Cover
3 B44613
1 12V solenoid
not shown
B44610
1 24V solenoid
4 A44622
1 Strain relief
5 B44616
1 RQE switch assembly (monitors cover side)
6
B44624
1 RQE switch assembly (monitors case side)
7
B44602
1 RQE and latch status switch holder
8
C44110 1 Key release lever
9
B45060
1 Deadbolt sub-assembly
10
C44104
1 Turn knob hub (deadbolt)
11
B34032
1 Turn knob hub cam
12
B45020
1 Latchbolt sub-assembly
13
C44144
1 Cylinder retainer
14
B45090
1 Cylinder retainer assembly
15
B44166
1 Fusible link molded assembly
16
C44142
1 Auxiliary bolt
17
C45000
1 Case sub-assembly
18
A44234
1 Self tapping screw
19
B44194
1 Deadlocking lever spring
20
C44148
1 Deadlocking lever
21
A44184
1 Deadlocking lever pin
22
C44538
1 Electrified hub (LH)
23
C44539
1 Electrified hub (RH)
Electronic locking toggle assembly
24
b
25
A44193
1 Release lever spring
26
C45010
1 Release lever sub-assembly
To Next Page
