Mortise Case Parts
TWEL function case
parts list
Refer to Figure 4.2 and the table below to find the part you need.
a. For a complete case, determine what type of solenoid and optional sensors you need.
Then use the table below to find the part number for the case. To order a “case only”
lock, which includes a mortise case, faceplate, and strike, see page 4–63.
Sensors Case part number
12 V solenoid 24 V solenoidRQE
C45699 C45700
C45736
C45737
b. To obtain the parts for the electronic locking toggle assembly, order:
locking slide (B44611)
locking bar (A44612)
electronic locking toggle (B44627)
toggle screws (see
Screw kits
on page 5–19)
.
40H Series Service Manual
4–55
Item
Part No.
a
Qty. Description
1 A34087 4 Case cover mounting screw
Cover
12V solenoid
24V solenoid
Strain relief
RQE switch assembly (monitors cover side)
RQE switch assembly (monitors case side)
RQE and latch status switch holder
Key release lever
Deadbolt sub-assembly
Turn knob hub (deadbolt)
Turn knob hub cam
Latchbolt sub-assembly
Cylinder retainer
Cylinder retainer assembly
Fusible link molded assembly
Auxiliary bolt
Case sub-assembly
Self tapping screw
Deadlocking lever spring
Deadlocking lever
Deadlocking lever pin
Electrified hub (LH)
Electrified hub (RH)
Electronic locking toggle assembly
Release lever spring
Release lever sub-assembly
2 D44010
1
3 B44613
1
not shown
B44610
1
4 A44622
1
5 B44616
1
6 B44624
1
7 B44602
1
8 C44110
1
9 B45060
1
10 C44104
1
11 A34032
1
12 B45020
1
13 C44144
1
14 B45090
1
15 B44166
1
16 C44142
1
17 C45000
1
18 A44234
1
19 B44194
1
20 C44148
1
21 A44184
1
22 C44538
1
23 C44539
1
24
b
1
25 A44193
1
26 C45010
1
