Mortise Case Parts
40H Series Service Manual
4–57
TWEU function case
parts list
Refer to Figure 4.2 and the table below to find the part you need.
a. For a complete case, determine what type of solenoid and optional sensors you need.
Then use the table below to find the part number for the case. To order a “case only”
lock, which includes a mortise case, faceplate, and strike, see page 4–63.
b. To obtain the parts for the electronic locking toggle assembly, order:
■ locking slide (B44611)
■ locking bar (A44612)
■ electronic locking toggle (B44627)
■ toggle screws (see
Screw kits
on page 5–19)
.
Sensors Case part number
RQE 12 V solenoid 24 V solenoid
C45694■ C45693
C45732
C45733
Item
Part No.
a
Qty. Description
1 A34087 4 Case cover mounting screw
Cover
12V solenoid
24V solenoid
Strain relief
RQE switch assembly (monitors cover side)
RQE switch assembly (monitors case side)
RQE and latch status switch holder
Key release lever
Deadbolt sub-assembly
Turn knob hub (deadbolt)
Turn knob hub cam
Latchbolt sub-assembly
Cylinder retainer
Cylinder retainer assembly
Fusible link molded assembly
Auxiliary bolt
Case sub-assembly
Self tapping screw
Deadlocking lever spring
Deadlocking lever
Deadlocking lever pin
Electrified hub (LH)
Electrified hub (RH)
Electronic locking toggle assembly
Release lever spring
2 D44010
1
3 B44613
1
not shown
B44610
1
4 A44622
1
5 B44616
1
6 B44624
1
7 B44602
1
8 C44110
1
9 B45060
1
10 C44104
1
11 A34032
1
12 B45020
1
13 C44144
1
14 B45090
1
15 B44166
1
16 C44142
1
17 C45000
1
18 A44234
1
19 B44194
1
20 C44148
1
21 A44184
1
22 C44538
1
23 C44539
1
24
b
1
25 A44193 1
To Next Page
