Best K29 - Service Parts List; Part Identification

- 13 -
KEY NO. PART NO. DESCRIPTION
7 B08091213 Filter Channel (48” models)
7 B08091111 Filter Channel (90cm models)
9 B08087163 Grease Filter
14 B02300233 Motor Capacitor
19 B03295005 Transformer Protection
26 B02300891 Halogen Lamp Bulb
37 B02300787 Heat Sentry
39 B03294033 Control Board Box Cover
42 B03295001 Filter Support
48 B02310201 Motor
49 B03295071 Blower Wheel
53 B03204177 Rubber Washer
62 B08091212 Blower Mounting Cover (48” models)
62 B08088597 Blower Mounting Cover (90cm models)
68 B02011258 Right Blower Housing
69 B02011259 Left Blower Housing
92 BE3233667 Controls Support
96 BE3245849 Transformer Support
109 BE3342578 Grease Filter Channel (48” models)
109 BE3333676 Grease Filter Channel (90cm models)
112 BE3345848 Electrical Box Support
113 B02011284 Nameplate
115 BE3404783 Wiring Box
116 BE3334252 Wiring Box Cover
118 BE3342581 Decorative Flue Bottom
119 BE3342582 Decorative Flue Top
120 B03292293 Flue Mounting Bracket
144 B03292287 Wire Clamp
147 BR2300135 Terminal Block
165 B03294781 Wiring Box
165 B03295008 Board Box
166 B08086668 Control Board
208 B02300792 Transformer (48” models)
208 B02300783 Transformer (90cm models)
223 B03200351 Switch Button
229 B03201014 Lamp Lens
240 B03292301 Switch Activator
274 B03295035 Fuse Box
474 B02300719 Halogen Lamp Housing
477 B03295006 Transformer Protection Cover
ARU B08092518 Duct Connector Assembly (Includes Key
Nos. 56, 57)
* B06002017 Blower Assembly (Includes Key Nos. 42, 48,
49, 53, 68, 69)
* B06107659 Control Board Assembly
(Includes Key Nos.14, 39, 144, 147, 165)
* B06107657 Switch Box Assembly (48” models)
(Includes Key Nos.92,223,228,230,234,240)
998 B080810595 Hardware Package
- B02300782 Fuse
- B02300674 Fuse Holder
* Not shown assembled.
SERVICE PARTS
MODEL K29 - Parts for stainless steel models shown. For service parts for black
or white models, call Broan Customer Service.
