51252 pg 2
0410 Rev. B
Parts List and Hardware Identification
Tools Needed
Phillips Head Screwdriver
3/8" Wrench
#10-24 Truss Head Machine Screw - Black,
Qty - 8, Part Number 195.92
#10-24 Locknut, Qty - 8,
Part Number 195.93
If your vehicle does not have the latch pin assembly illustrated here,
you have an incorrect part for your vehicle. Please call the 1-800
number before attempting installation.
Latches - Rotary Paddle Handle -
Rt., Qty - 1, 454.42
Lt., Qty - 1, 454.43
Special Note: The Rotary Latch Paddle Handle will only latch on
the automobile manufacturer's original equipment steel latch pin
located on the vehicle. Do Not adjust or remove this part.
STOP
Spacer Kit , Qty - 1, Part Number 287.59
