2.2.3 Install the binocular viewing head
(Fig.5-6)
Insert the binocular viewing head in the
head of the body, turn to the right place, then
fixupitbybolts
2.2.4 Install the eyepiece (Fig.7-8)
Insert the eyepiece in the eyepiece tube till
end. Fig.8 picture shows the station after
the installing.
Fig.8
