Beta 1760/A - MEASURING CURRENT

EN
18
4. You can get reading from LCD. The polarity of the red lead connection will be indi-
cated along with the voltage value when making DC voltage measurement.
NOTE:
> When only the figure “1” or “-1” is displayed, it indicates overrange situation and the higher
range has to be selected.
> When the value scale to be measured is unknown beforehand, set the range selector at the
highest position.
> means you can't input the voltage which more than 1000V DC or 700V rms AC, it's
possible to show higher voltage, but it's may destroy the inner circuit.
> Pay attention not to get an electric shock when measuring high voltage.
4.5 MEASURING CURRENT
1. Connect the black test lead to the COM jack and the red test lead to the mA jack for
a maximum of 200mA current. For a maximum of 10A, move the red lead to the
10A jack.
2. Set the rotary switch at the desired A or A~ range position.
3. Connect test leads in series with the load under measurement.
4. You can get reading from LCD. The polarity of the red lead connection will be indi-
cated along with the voltage value when making DC Current measurement.
