Set the function switch to the Ω position.
Insert the black test lead plug into the negative (COM) socket and the red test lead plug into
the positive Ω jack.
Press the MODE button until “Ω” appears in the display.
Touch the test probe tips across the circuit or part under test. It is best to disconnect one side of
the part under test so the rest of the circuit will not interfere with the resistance reading.
Read the resistance in the display. The display will indicate the proper decimal point, value
and symbol.
CONTINUITY CHECK
WARNING:
To avoid electric shock, never measure continuity on circuits or wires that have voltage on
them.
Set the range switch to the
position.
Insert the black lead plug into the COM socket and the red test lead plug into the positive •)))
socket.
Press the MODE button until “
” appears in the display.
Touch the test probe tips to the circuit or wire you wish to check.
If the resistance is less than 30Ω, the audible signal will sound. The display will also show the
actual resistance in ohms
