CAPACITANCE MEASUREMENT
WARNING:
To avoid electric shock, discharge the capacitor under test before measuring.
Set the function switch to the CAP capacitance position.
Insert the black test lead banana plug into the negative COM jack and the red test lead banana
plug into the CAP positive jack.
Touch the test probe tips across the part under test.
Read the capacitance value in the display.
The display will indicate the proper decimal point and value.
Note:
For very large values of capacitance measurement time can be several minutes before the nal
reading stabilizes. The LCD displays
DSC when discharging. Discharging through the chip is
quite slow. We recommend the user to discharge the capacitor with some other apparatus.
