BT-532C User manual
3
3) Power on, press the [feed] key, it will print out one testing sample.
2.Technical Specifications
3. Pin Definition
CN1 （USB connector）
Standard definition
CN2 （25 pin Parallel）
Standard definition
CN3 （9pin Serial）
Standard definition
CN4 （4PIN power socket）
Print Method
Line thermal printer
Paper Width
80mm
Printing Width
72mm
Resolution
203DPI
Resolution Ration
576 dots
Printing Speed
50mm/s
Printing Content
ASCII CH(8x16,9x17,9x24,12×24,); GBK(16x16,24×24),One-dimension Bar
Code ,support printing different dot diagram and download bitmap.extensible
two-dimension bar code.
Font
9X17(ASCII),24x24(Chinese)
Pin
Function
1
GND
2
+24V
3
+24V
4
GND
