3. Description of device
Protective cap
LCD-Display
Front side
Rear side
“SCAN” button
On/Off/Memory button
Battery compartment cover
Battery compartment unlocking
Sensor tip
green LED
red LED (fever alarm)
SCAN
4. Functions
This infrared thermometer is for measuring
– temperature at a person’s forehead,
– surface temperature of objects and liquids,
– ambient temperatures.
The thermometer also offers additional functionalities:
– 9 memory locations for simple plotting of changes in temperature,
– date and time, also with all stored temperatures measured,
- Optical and acoustic fever alarm at temperatures over 37.5 °C,
- switchable to °C and °F.
5. Operation
Remove the protective cap and switch on the thermometer with the “ ” button. After a short self-test
and two short beep tones, the thermometer is ready for forehead temperature measurement.
