3.3.9 Table of programmable functions
No. Description Value
range
Factory
setting
00 Save or load setups 1 ... 7 -
01 Max. volume 0 ... 32 32
02 Volume setting with the “Vol” buttons
1 = enabled
0 = disabled
0 or 1 1
03 Max. limit for “Voice” mode 0 ... 8 8
04 Max. limit for “Free” mode 0 ... 8 8
05 Max. limit for “Request” mode 0 ... 8 8
06 Separate “Voice” threshold for MCS 223 (applies, when function 07 is set to
1, otherwise the general “Voice” threshold applies. Refer also to function 08.)
1 ... 84 40
07 Separate “Voice” threshold for MCS 223 activated (refer to function 06)
0 = no separate
1 = separate
0 or 1 0
08 MCS 223 “Voice activation”
0 = only in the “Voice” mode
1 = in all operating modes
2 = never (when “2” is selected, the microphone is only activated via the
microphone button)
0 ... 2 0
09 no function (must be set to “0”) 0
10 MCS 223 “Priority” is linked with the microphone button:
0 = not linked
1 = linked (“Priority” function is also released via the microphone button)
0 or 1 0
11 MCS 223 “Priority” button:
0 = push button mode
1 = latching mode
2 = Auto-OFF (Auto-Off depends on the general or separate “Voice”
threshold; function 06)
0 ... 2 0
12 MCS 223 Microphone button:
0 = push button mode
1 = latching mode
2 = Auto-OFF (Auto-Off depends on the general or separate “Voice”
threshold; function 06)
0 ... 2 1
13 MCS 223 “Clear” button:
0 = short press: turn off activated microphone units;
long press: turn off activated and registered microphone units
1 = turn off activated and registered microphone units always; independing on
how long the button is pressed
0 or 1 0
