Opus 600 – S 600 Handheld Transmitter
46
3. S 600 handheld transmitter
3.1 Controls and indicators
There are different condenser and dynamic microphone capsules for the handheld transmitter (refer to
chapter 10. Optional accessories).
Microphone capsule (can be unscrewed)
Battery status indicator
On-off switch
Infrared diode (at the bottom of the transmitter)
3.2 How to insert the batteries /
rechargeable batteries
1. Unscrew the battery cap counter-clockwise.
2. Insert two 1.5 V batteries (AA) or fully charged
NiMH batteries into the battery compartment
observing the polarity markings.
3. The battery status indicator should flash for a
moment. If the battery status indicator does not
flash, the battery is not inserted correctly or empty.
Insert the battery correctly or replace it.
S 600
