3 -
DESCRIPTION OF MACHINE
3.1 Description of working cycle
BZ16 S/R/TOP Versions
The water coming from the water supply (BZ16 R - BZ16 TOP-DIRECT WATER CONNECTION VERSION)
or from the tank on the back of the machine (BZ16 S - BZ16 TOP-TANK VERSION), via a pump, passes
through a excess pressure valve regulated to 12 bar (1.2 MPa) and allows the boiler and the exchanger
to be loaded. The boiler water, heated up through a resistor, heats up the exchanger water from which,
thanks to a dip pipe, is convoyed to the group in order to brew the coffee by means of a valve electronically
controlled.
3.2 Description of commands
(Fig. 01 - Fig. 09)
1 Main switch
2 Coffee s
witch
3
Hot Water Nozzle
4
Water Inlet Pipe (R version)
5
Power Supply Cable
6
Brewing Group
7
Filter Holder
8
Steam Nozzle
9
Steam tap
10
Hot water tap
11
Power Light
12
Level Light
13
Drain pipe (R version)
14
Boiler’s gauge
15 Pump’s gauge
16 Blind filter
17 2 cup filter
18 1 cup filter
19 Light switch
3.3 Technical data (Fig. 02)
Power Supply V~/Hz 220 – 240V~ / 50-60Hz 110 – 120V~ / 50-60Hz
Resistance V~ 220 - 240 110
Nominal power W 1450 - 1650 1550
Resistance W 1250 - 1450 1350
Boiler lt 2,0
Tank (S) lt 4,0
Width “A” mm 320
Depth “B” mm 450
Height “C” mm 400
Net Weight kg 22.7 (vibration pump) S = 28.2 (volumetric pump) R/TOP
Gross Weight (box) kg 25.2 (vibration pump) S = 30 (volumetric pump) R/TOP
Nipple for water supply (R) G 3/8”
Drain Connector Diameter (R) mm 10
3.2.1 Description of command panels
(Fig. 05)
2a Key for regular coffee
2b Key for long coffee
2c Key for double dose of regular coffee
2d Key for double dose of long coffee
2e Key for programming
