DESCRIPTION OF MACHINE
3.1 Description of working cycle
S/R/TOP Versions
The line pressure of the water directly coming from the water supply line (VERSION R) or, by means of
a pump, from the tank located on the rear of the machine (VERSION S - TOP-TANK) or from the water
supply line (VERSION TOP-DIRECT WATER CONNECTION), enables to load the boiler and, through
a relief valve set to 12 bar (1.2 MPa), the exchanger load.
The water in the boiler, heated by a resist-
ance, warms the water in the exchanger. Lowering the group lever, the water is directly pumped from the
exchanger to the group chamber; when the group lever is released, coffee is brewed.
3.2 Description of commands (Fig. 01 - Fig. 09)
1 Main switch
2
Brewing coffee lever
3
Hot Water Nozzle
4
Water Inlet Pipe (R/TOP version)
5
Power Supply Cable
6
Brewing Group
7
Filter Holder
8
Steam Nozzle
9
Steam tap
10
Hot water tap
11
Power Light
12
Safety light
13
Drain pipe (R version)
14
Boiler’s gauge
15 2 cup filter
16 1 cup filter
3.3 Technical data (Fig. 02)
Power Supply V~/Hz 220 – 240V~ / 50-60Hz 110 – 120V~ / 50-60Hz
Resistance V~ 220 - 240 110
Nominal power W 1450 - 1650 1550
Resistance W 1250 - 1450 1350
Boiler lt 2,0
Tank (S) lt 4,0
Width “A” mm 330
Depth “B” mm 450
Height “C” mm 710
Net Weight kg 28 (S version) = 31 (R version)
Gross Weight (box) kg 30.5 (S version) = 33.5 (R version)
Nipple for water supply (R) G 3/8”
Drain Connector Diameter (R) mm 10
