5
HTE402559 32/47
4 3 2 1
COM
ERR N2 N1
E-Con1
○ Dry contacts or an open collector
2.2KΩ
N
1
2
DC24
Inner Circuit
2.2KΩ
N1
N2
COM
N1
N2
COM
+12V
○ External voltage
2.2KΩ
N
1
2
DC24
Inner Circuit
2.2KΩ
N1
N2
COM
DC12～24V
N1
N2
COM
DC12～24V
Output of error signal
Select control by 4-20mA
current or Two-rate-of-feed
with a slide switch on
the print circuit board.
Output transistor closes by error
such as “E-OL” and so on.
Maximum output voltage: DC24 V
Maximum output current: 80mA
Connection Diagram
Factory Default
ERR
COM
Inner Circuit
