BFC VMC Series User Manual

5
HTE402559 45/47
Model VMC-101SF
VMC-103SF VMC-105SF
Power Source AC200～230V±10% AC100～120V±10% 50／60Hz
Control Type PWM
Output
Voltage
0～190V（Input power 200V system） 0～95V（Input power 100V system）
Frequency
Half-wave：45～90Hz
Full-wave：90～180Hz
High-frequency：180～360Hz
Middle-frequency：65～120Hz
The maximum
current
1A 3A 5A
Operation
mode
Auto-tuning mode
The
output drive frequency chases the resonant frequency of the drive unit
automatically and VMC-controller controls the stroke constant.
Constant stroke
mode
VMC-controller controls the stroke constant at the preset drive frequency.
Constant voltage
mode
VMC-controller outputs the constant voltage at the preset frequency
Additional
function
Speed change An external signal selects any stroke setting out of four preset values.
Run/Stop operation
An external signal runs or stops the partsfeeder.
Output signal
VMC-controller
outputs a synchronous signal with running and stopping of the
partsfeeder.
Soft start Ramp-up time 0.2 to 4 seconds
On and Off delay Delay time 0.2 to 60 seconds
Power source for
sensors
With a 3 cored socket plug
Synchronous
power output
Function Power output synchronous with the partsfeeder operation
Control method Run/Stop with a triac
Output voltage Same as Power Sorce
Maximum current 2A
Applicable
condition
Ambient
temperature
0～40℃
Ambient moisture 10～90％（No condensation is allowed.）
Workable location
Indoor without corrosive gas and dust or harmful circumstance
Noise resistance 1000V or more
Color of case BLUE B75-40L （JAPAN PAINT MANUFACTURERS ASSOCIATION）
Outline
dimensions
59W×170H×150D
（without mass of plug connectors）
119W×170H×150D
（without mass of plug
connectors）
Mass 0.9Kg 1.0Kg 1.6Kg
Applicable
model
Partsfeeder
MB-230D(200V)
MB-230D (100V)
MB-300D
MB-390D（200V）
MB-460D（200V）
MB-390D（100V）
MB-460D（100V）
MB-610D
MB-700D
Linear feeder
ML-001JD
ML-001RD
ML-002JD
ML-002RD
――――― ―――――
