BFT COMPASS 485 - Door Alarm

Fig. 3
T0.1A
DIP SWITCH
1 2 3 654
1 2 3 4 5 6 7 8
7
8
9
10
11
12
13
14
15
16
17
18
A
L N
230V
DOOR ALARM
B
COM
OPEN
DOOR
+12V d.c.
D1
-
12V d.c.
DØ
LED
A
LED
B
COMPASS
485
COMPASS
485
COMPASS
READER 2
+12V d.c.
D1
GND
DØ
LED
A
LED
B
COMPASS
READER
1
NO
COM
NC
NO
COM
ON
OFF
COMPASS
485
COMPASS-READER
6 5 4 3 2 1
+12 V d.c. D1 DØ - LED B
LED
A
JP1
3-4
Relè Apertura Porta - Door Opening Relay
Relais Ouverture Porte - Türöffnungsrelais
Relé Apertura Puerta - Relé de Abertura da Porta
5-6-7
Relè Allarme - Alarm Relay
Relais Alarme- Alarmrelais
Relé Alarma - Relé de alarme
JP1a
JP1b
*
*
28 - COMPASS-485/232 - Ver. 04
D811320_04
