BFT EOS 1200 U - Table “C” - Radio Menu (Radio); Serial Mode

D812774 00100_06
EOS 1200 U - 35
ENGLISH
INSTALLATION MANUAL
Logic Denition
De-
fault
Cross
out
setting
used
Optional extras
SERIAL MODE
Serial mode
(Identies how
board is congured
in a BFT network
connection).
0
0 Standard SLAVE: board receives and communicates commands/diagnostics/etc.
1 Standard MASTER: board sends activation commands (START, OPEN, CLOSE, PED, STOP) to other boards.
ADDRESS
Address 0
[ ___ ]
Identies board address from 0 to 119 in a local BFT network connection.
(see U-LINK OPTIONAL MODULES section)
IC 1
Conguration of
command input
IC 1.
0
0 Input congured as Start E.
1 Input congured as Start I.
2 Input congured as Open.
IC 2
Conguration of
command input
IC 2.
4
3 Input congured as Close.
4 Input congured as Ped.
sw mov
Movement to
limit switch
1
0 Logic not enabled
1 Enables movement reversal when it stops at the travel limit
TABLE “C”  RADIO MENU RADIO
Logic Description
Add start
Add Start Key
associates the desired key with the Start command
add 2ch
Add 2ch Key
Associates the desired key with the 2nd radio channel command. If no output is congured as 2nd Radio Channel Output, the 2nd radio chan-
nel controls the pedestrian opening.
erase 64
Erase List
WARNING! Erases all memorized transmitters from the receiver’s memory.
Read
Read
Checks a key of a receiver and, if memorized, returns the number of the receiver in the memory location (from 01 to 64) and number of the key
(T1-T2-T3 or T4).
Read receiver code
Displays receiver code required for cloning transmitters.
ON = Enables remote programming of cards via a previously memorized W LINK transmitter.
It remains enabled for 3 minutes from the time the W LINK transmitter is last pressed.
OFF= W LINK programming disabled.
