Art. 2832
Creeper Seat with Drawer
EXPLODED VIEW
PART LIST
No. Description Qty No. Description Qty No. Description Qty
1 Drawer
1
5 Nut M8
4
8 Plastic Tray 1
2 Seat
1
6 Spring Washer 8 4 9 Frame 1
3 Washer 6 mm
4
7 Flat Washer 8 4 10 Wheel 4
4 Screw M6x45
4
ASSEMBLY
1. Put the plastic insert (8) into the frame (9).
2. Stuck bolts of castors (10) from below into the frame.
3. Fix the castors with washers (3) - spring washers (6) - Nuts (5).
4. Put one washer (3) on each screws (4).
5. The drawer (1) must be mounted in the frame before the next step.
6. Put the seat on the frame and tighten it with the screws (4).
SSSSSSSSS
SPECIFICATIONS
Sturdy Frame (25 x 25 mm)
Castors Ø 50 mm (4 pcs.)
Seat: (w)365 x (d)210 mm
Drawer Dimensions: (w)275 x (d)185 x (h) 55 mm
Dimensions: (w)360 x (d)410 x (h)330 mm
Max. Capacity: 90 Kg
S
AFETY ADVISE
• Do not exceed the max. capacity of 90 kg.
• Only use the creeper seat on level ground.
• Check the creeper seat for damage before
use.
• Do not use a damaged creeper seat.
• Do not stand on the creeper seat.
• Do not allow children to play with the
creeper seat.
