Instruction Manual
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
www.bgstechnic.com
BGS 3060
Double Flaring Tool
TOOLS
1 Pressing Tool
2 Pressure spindle
3 Cone
4 Fixing frame
5 Pressure piece 4.75 mm
6 Pressure piece 5 mm
7 Pressure piece 1/4"
8 Pressure piece 6 mm
9 Pressure piece 8 mm
10 Pressure piece 10 mm
11 Pressure piece 1/2"
I
NTENDED USE
This tool set is used to produce D, E & F type flare.
The tools are suitable for cable diameters 4.75 - 5 - 6 - 8 - 10 mm - 1/4" and 1/2".
A
TTENTION
Read these operating instructions carefully and observe all safety instructions before using the
product.
S
AFETY INFORMATION
• Repairs to brake systems should only be carried out by trained persons with experience.
• Only use the tool set for the purpose for which it is designed.
• Do not use the tool if parts are missing or damaged.
• When using the product, be sure to wear the correct safety clothing and take protective
m
easures.
• The use of protective gloves, safety glasses and safety shoes is recommended.
• Check the condition of the tool regularly and replace damaged parts.
• Always keep the spindle clean and well oiled. Careful maintenance guarantees the operational
readiness and longevity of the tool.
• Before use, familiarise yourself with the correct use of the tool to be used, taking into account the
necessary safety measures.
•
Always follow the instructions of the vehicle manufacturer.
