Instruction Manual
BGS technic KG
Bandwirkerstr. 3
42929 Wermelskirchen
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
BGS 566
Hole Punch Set (14-piece)
GENERAL
This set helps punching holes in (e.g.) sealing compounds, cardboard etc.
It contains thirteen exchangeable hole punches (Ø 5 – 6 – 8 – 10 – 11 – 13 – 16 – 19 – 22 – 25 – 28 -
32 and 35 mm), a quick change punch holder with ergonomic handle design and a
spring loaded centering pin.
NOTE
Best results will be achieved when using it on an even
and flat surface.
Wood is your surface of choice because metal
or other very hard surfaces may damage your hole punches.
OPERATION
1. Mark the center of the hole to be punched out.
2. Choose the appropriate hole punch and screw it on the
punch holder.
3. Apply the spring loaded centering pin at the marked
center.
4. Hold the punch holder vertically to the work piece.
5. Hit the top of the punch holder with a hammer. Note:
Hitting too hard may damage your hole punch while
hitting too soft may not create a proper hole in your work
piece.
diameter of the
punched out hole
center of the
punched out hole
