Instruction Manual
BGS technic KG
Bandwirkerstr. 3
42929 Wermelskirchen
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
www.bgstechnic.com
Art. 66205
Timing Tool Set for
AUDI / VW 2.7 and 3.0 TDI
GENERAL
This set is suitable for Audi A4, A5, A6, A8, Q5, Q7 and VW Touareg, Phaeton with engine code:
ASB, BKN, BKS, BMK, BMZ, BNG, BPP,BSG, BUG, BUN, CAMA, CAMB, CANA, CANB, CANC,
CAND, CAPA, CARA, CARB, CASA, CASB, CASC, CATA, CCMA, CCWA, CCWB, CDYA, CDYB,
CDYC, CEXA, CGKA, CGKB and is required for controlling or adjusting the engine valve timing.
SAFETY ADVICE
x These instructions are for illustrative purposes only, not to replace a repair-manual.
x Use for testing, adjusting and diagnostic work always vehicle-specific service literature, otherwise
can damage to the engine.
x Be careful when working on hot engines!
x Use caution when working on running engines, loose clothing, tools and other items can be
collected from rotating parts and cause serious injuries.
x Always follow occupational health and safety regulations.
x Assure the vehicle against unintended starting, before applying the tool.
CONTENT
1
Adaptor for camshaft to be used as OEM T40061
2
Adaptor for chain wheel to be used as OEM T40062
3
Adaptor for drive plate to be used as OEM T40049
4
Adaptor for crankshaft to be used as OEM T40058
5
Camshaft locking bolt 2x to be used as OEM T40060
6
Locking pin for injection pump to be used as OEM 3359
7
Locking pin for chain tensioner 2x
8
Crankshaft locking bolt to be used as OEM 3242
1 2 3
5
4
6
7
8
