Instruction Manual
BGS technic KG
Bandwirkerstr. 3
42929 Wermelskirchen
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
www.bgstechnic.com
Art. 7744
10-piece Bearing Puller Set
Puller with interchangeable heads Ø 5, 6 and 8 mm and maximum range at 100 mm.
Instructions
1. Drill with a suitable drill through the cage of the bearing.
2
. Destroy the cage, so that one or two bearing balls can be moved till there
is enough space for a puller ball. Same procedure applies to the opposite
side.
3. Insert puller balls and turn by 90°, the ball can no longer be pulled out
from bearing.
4. Mount puller legs, spindle and puller balls at the adapter.
5. If all puller parts are mounted, turn spindle clockwise and pull out the
bearing.
Warning
If working with this tool always wear secure gloves and glasses
Important Note
Keep all threads are clean and oil it before use!
Do not use an impact wrench, this will damage the spindle.
