17
To adjust the running belt, stop the treadmill,
then use the Hex Wrench and adjust the Hex
Screw located in the Rear End Cap. If the running
belt is moving towards the left side, tighten the
left Hex Screw about 1/4 turn (clockwise); if the
running belt is moving towards the right side,
tighten the right Hex Screw about 1/4 turn
(clockwise); Turn the treadmill on after it has
been adjusted. If you nd that the belt has not
moved to the proper position, please repeat the
steps above. Don’t use the treadmill until the
running belt returns to the center position.
e position of running belt might not stay
precisely in the center, it can and will shift
slightly towards the left and right sides, however,
you do not need to adjust the belt if it is not
rubbing against the side rails.
Depending on the usage of the product, please
apply silicon according to the chart to the right.
Use the Hex Wrench to unscrew the bolt inside
the Rear Roller. en pull the belt up and put
some silicon to the center of the board. After
that, adjust the belt to the center of the deck,
followed by tightening the screw to the original
set.
When the belt is sliding, please follow the above
method to lubricate the running board.
KGS/LBS Speed Interval
KGS
6KM/hr Below 1 year
6~12KM/hr 6 months
12KM/hr Above 3 months
LBS
4mile/hr Below 1 year
4~8mile/hr 6 months
8mile/hr Above 3 months
Note: This maintenance is intended for household
use. If used for business, it is suggested to
examine the product every other month.
Silicon Chart
BELT ADJUSTMENTS
