PARTS LIST
To order replacement parts: provide your customer service representative with the product model
number and the part number located on the Parts List below, along with the quantity you require.
No. Description Qty No. Description Qty
S5Ti-1 Base frame
1
S5Ti-60 Plastic bushing
1
S5Ti-2 Main frame
1
S5Ti-61 Plastic bushing
1
S5Ti-3 Incline frame
1
S5Ti-62 Side rail
2
S5Ti-4 Upright post ( L & R )
2
S5Ti-63 Lower control board
1
S5Ti-5 Computer frame
1
S5Ti-64 Transformer
1
S5Ti-6 Console bracket
1
S5Ti-65 Plastic strips
8
S5Ti-7 Foot pedal release
1
S5Ti-66 Ipad tray
1
S5Ti-8 Motor base frame
1
S5Ti-67 Power cord
1
S5Ti-9 External extension tube frame
1
S5Ti-68 Washer Φ5
1
S5Ti-10 Internal extension tube frame
1
S5Ti-69 Wire (red)
1
S5Ti-12 Adjustable foot
4
S5Ti-70 Wire (black)
1
S5Ti-13 Allen C.K.S. full thread screw M8*15
12
S5Ti-71 Breaker switch
1
S5Ti-14 Transportation wheel
4
S5Ti-72 Power switch
1
S5Ti-15 Flat washer (Φ8)
22
S5Ti-73 Cable ring
1
S5Ti-16 Self-xing bolt M8
9
S5Ti-74 Motor belt
1
S5Ti-17 Main cable L-1200
1
S5Ti-75 Shock absorber Φ30×M6
4
S5Ti-18 Controller cable L-800
1
S5Ti-76 Cushion with holder
2
S5Ti-19 Console housing (front)
1
S5Ti-77 Hex bolt
4
S5Ti-20 End cap (front)
2
S5Ti-78 Allen C.K.S. half thread screw M8*35*20
2
S5Ti-21 End cap (rear)
2
S5Ti-79 End cap (Left)
1
S5Ti-22 Handle pulse grip
2
S5Ti-80 End cap (Right)
1
S5Ti-23 Phillips C.K.S. self-tapping screw ST3*25
4
S5Ti-81 Foot pad
2
S5Ti-24 Foam grip (left, right)
2
S5Ti-82 Phillips C.K.S. full thread screw M5*10
11
S5Ti-25 Phillips C.K.S. self-tapping screw ST4*20
8
S5Ti-83 Phillips C.K.S. full thread screw M5*15
6
S5Ti-27 Phillips C.K.S. self-tapping screw ST4*16
46
S5Ti-84 Front roller
1
S5Ti-28 Phillips self-tapping screw ST3*10
6
S5Ti-85 Allen socket head half thread screw M8*65
2
S5Ti-29
Phillips C.K.S. steel self-tapping screw
ST4*12
12
S5Ti-86 Running deck
1
S5Ti-30 Allen socket full thread screw M6*25
4
S5Ti-87 Allen countersunk full thread screw M6×30
6
S5Ti-31 Console housing (rear)
1
S5Ti-88 Phillips countersunk self tapping screw
2
S5Ti-32 Allen C.K.S. half thread screw M8*30
2
S5Ti-89 Cable guide
2
S5Ti-33 Cable L-700
1
S5Ti-90 Side rail guide
6
S5Ti-34 Console board (PCB)
1
S5Ti-91 Rear roller
1
S5Ti-35 Fan
1
S5Ti-92 Allen screw M8*75
2
S5Ti-36 Sensor bracket
1
S5Ti-93 Running belt
1
S5Ti-37 Console tray (upper) with keyboard
1
S5Ti-94 Motor cover
1
S5Ti-38 Console tray (lower)
1
S5Ti-95 End cap Φ32
2
S5Ti-39 Safety key
1
S5Ti-96 Allen socket head full thread screw M8*40
1
S5Ti-40 Clinker
1
S5Ti-97 Allen C.K.S. full thread screw M8*20
2
S5Ti-41 Motor
1
S5Ti-98 Fan plate
3
S5Ti-42 Speed sensor
1
S5Ti-99 Bracket (left)
1
No. Description Qty No. Description Qty
To Next Page
