BIFFI ICON3000 Advanced Maintenance Instructions

March 2021
Installation, Operation and Maintenance Manual
MDE 257 Rev. 1
26
Alarm "Conguration n°"
Section 4: Alarm "Configuration n°"
Table 26. Serial Number
Nameplate
Obj n° Value Function Description
300 031234E01003 Serial number Max. 12 characters
Table 27. Actuator Size
Nameplate
Obj n° Value Function Description
301 ICON-010-40-90 Actuator size Max. 28 characters
Table 28. Wiring Diagram
Nameplate
Obj n° Value Function Description
302 WD-80-AT-000 Wiring diagram Max. 28 characters
Table 29. Enclosure
Nameplate
Obj n° Value Function Description
303 Eex-d-IIC Enclosure Max. 28 characters
Table 30. Certificate
Nameplate
Obj n° Value Function Description
304 ATEX Certificate Max. 28 characters
Table 31. Lubricant
Nameplate
Obj n° Value Function Description
305 SHELL_TIVELA Lubricant Max. 28 characters
Table 32. Torque / Thrust
Nameplate
Obj n° Value Function Description
532 Nm Torque, thrust engineering unit ft-lbf, Nm, lb, KN
307 90 Torque, thrust nominal value Max. 28 characters
Table 33. Actuator Speed
Nameplate
Obj n° Value Function Description
132 RPM Actuator speed engineering unit s/90°, RPM, mm/s, in/s
308 48 Actuator speed value Actuator speed, max. 28 characters
