Channel Value Function
116-122
123-129
130-136
137-143
144-150
151-157
158-164
165-171
172-180
181-215
216-220
221-255
PRISM
000-010
11-127
128-255
FROST
000-127
128-255
CONTROL
000-040
041-070
071-100
101-120
121-130
131-140
141-150
151-255
GOBO 6 Shaking ( slow to fast)
GOBO 7 Shaking ( slow to fast)
GOBO 8 Shaking ( slow to fast)
GOBO 9 Shaking ( slow to fast)
GOBO 10 Shaking ( slow to fast)
GOBO 11 Shaking ( slow to fast)
GOBO 12 Shaking ( slow to fast)
GOBO 13 Shaking ( slow to fast)
WHITE
Clockwise Rotation Fast to Slow
Stop
Counter-Clockwise Rotation Slow to Fast
PRISM
CLOSE
OPEN
PRISM ROTATION (SLOW TO FAST)
FROST
CLOSE
OPEN
CONTROL
NO FUNCTION
LAMP OFF
LAMP ON
NO FUNCTION
P/T RESET
EFFECT RESET
ALL RESET
NO FUNCTION
CH9
CH10
CH11
CH12
— 7 —— 6 —
Error Infromation
The RED light of Error indicator are shown when the fixture fails and they will not disappear until the
fixture is repaired.
1. CPU-A/B Error
Check whether the 485 (DATA) leads on the PCB board are installed in place or disconnected.
Check whether the related 485 (DATA) signal circuit on the PCB board is damaged.
2. Pan Encode Error
Check whether the encoder on the pan is damaged.
Check whether the lead connecting the encoder on the pan and the PCB board is in poor contact
or disconnected.
3. Tilt Reset Error
Check whether the position of the tilt where the magnet is installed falls off or is damaged.
Check whether there are obstacles in the tilt operating range.
Check whether the Hall element on the tilt is damaged.
Check whether the lead connecting the Hall element on the tilt and the PCB board is in poor
contact or disconnected.
Check whether the motor on the tilt is damaged.
Check whether the related circuit of the motor drive board on the tilt is damage.
4. Tilt Encode Error
Check whether the encoder on the tilt is damaged.
Check whether the lead connecting the encoder on the tilt and the PCB board is in poor contact or
disconnected.
Trouble-shooting
Following are a few common problems that may occur during operation. Here are some
suggestions for troubleshooting:
A. The unit does not work, no light and the fan does not work
1. Check the connected power.
2. Measure the voltage.
3. Check the power indicator to see whether it can be lit up or not.
B. Not responding to the DMX controller
1. Check whether the DMX connectors and the DMX cables are connected correctly.
2. Check whether the DMX address is correctly set.
3. If the intermittent DMX signal problem occurs, check whether the XLR socket and the signal cable are well
connected.
4. Try it with another DMX controller.
5. Check whether the DMX cables run near or alongside to the high-voltage cables, which may damage or
interfere with the signal circuit.
C. One of the channels is not working well
1. The stepper motor might be damaged or the cable connected to the PCB might be broken.
2. The motor’s drive IC on the PCB might be out of condition.
D. The lamp is cutting out intermittently
1. The lamp is not working well. Check whether the voltage is too high or too low.
2. The internal temperature may be too high. Replace the cooling fan if necessary.
It is absolutely essential that the fixture is kept clean to ensure the maximum light-output and allow the fixture to
function reliably throughout its life. The fixture must be cleaned regularly to avoid dust, dirt and smoke-fluid
residues building up on or within the fixture. The cleaning frequency depends on the application environment.
Clean the fixture immediately if the dust enters it to avoid damage to the optical lens due to excessive dust.
A soft lint-free cloth moistened with any good glass cleaning fluid is recommended, under no circumstances
should solvents be used.
Always dry the parts carefully.
Clean the external optical lens at least every 20 days and the internal optical lens every.
5. Color Reset Error
Check whether the position of the color wheel where the magnet is installed falls off or is damaged.
Check whether there are obstacles in the color wheel operating range.
Check whether the Hall element on the color wheel is damaged.
Check whether the lead connecting the Hall element on the color wheel and the PCB board is in
poor contact or disconnected.
Check whether the motor on the color wheel is damaged.
Check whether the related circuit of the motor drive board on the color wheel is damage.
6. Gobo Reset Error
Check whether the position of the gobo wheel where the magnet is installed falls off or is
damaged.
Check whether there are obstacles in the gobo wheel operating range.
Check whether the Hall element on the gobo wheel is damaged.
Check whether the lead connecting the Hall element on the gobo wheel and the PCB board is in
poor contact or disconnected.
Check whether the motor on the gobo wheel is damaged.
Check whether the related circuit of the motor drive board on the gobo wheel is damage.
7. Lamp Fan1 Start Err
Check whether the fan is not running.
Check whether the fan leads are installed in place or disconnected.
Check whether the fan is damaged.
Check whether there are obstacles in the fan operating range.
