REV E 6-2 119293
12. Level the front of the deck by turning the lock nut, at
the front of the mower, until the correct distance from
the ground to the top of the deck is attained.
Figure 6-11
A. Measure to top of deck
Figure 6-3
A
A. Measure to top of deck
Figure 6-4
A. Hardware B. Cam
Figure 6-5
A
A
B
