A. 3/8” drive extension B. Cam
Figure 6-6
Hold the bolt and outer nut so cam does not move while
tightening the inner nut.
A. Bolt B. Outer nut
Figure 6-7
A
B
A
B
Tighten the inner nut to prevent slipping of the adjustment.
A. Inner nut
Figure 6-8
Hold the bolt so cam does not move while tightening the
inner nut.
A. Bolt
B. Cam
C. Outer nut
Figure 6-9
