5.3.7. Hydraulic components
For main hydraulic diagram see chapter 3.5.1
Main hydraulic components spare parts
Table 15.
Pos.
Art. No.
Description
Note
1
913260L
Tipping / Rolling cylinder 160/80-1790
1
913260R
Tipping / Rolling cylinder 160/80-1790
37913255
Sealing kit for hydraulic cyl. 160/80
37913256
Front bush for hydraulic cyl. 160/80
37913258
Piston for hydraulic cyl. 160/80
2 913245
Telescope cylinder 125/63-1300 with
pilot operated valve
37913240
Sealing kit for hydraulic cyl. 125/63
37913241
Front bush for hydraulic cyl. 125/63
37913243
Piston for hydraulic cyl. 125/63
3, 4
313158
Bogie block / lift cylinder 100/60-180
37313160
Sealing kit for hydraulic cyl. 100/60
37313162
Front bush for hydraulic cyl. 100/60
37313163
Piston for hydraulic cyl. 100/60
5
913210
Brake cylinder 40/20-60
37913210
Sealing kit for hydraulic cyl. 40/20
37913212
Front bush for hydraulic cyl. 40/20
37913213
Piston for hydraulic cyl. 40/20
6
913235
Starting point cylinder 100/70-160
37913235
Sealing kit for hydraulic cyl. 100/70
37913236
Front bush for hydraulic cyl. 100/70
37913238
Piston for hydraulic cyl. 100/70
7
913230
Operation changing cylinder 50/32-70
37913230
Sealing kit for hydraulic cyl. 50/32
37913232
Front bush for hydraulic cyl. 50/32
37913233
Piston for hydraulic cyl. 50/32
8
913630
Pilot operated valve
9
913640
End of stroke valve
11
915201
Pilot operated double check valve
13
914570
Brake quick coupling ½
For frame lock hydraulic diagram see chapter 3.5.2
